| Key Features | Data Rate |
|---|---|
| 2.4 GHz: 300 Mbps 5 GHz: 867 Mbps | Antenna |
| 4× 5dBi Fixed High Gain Antennas | Button |
| WPS Button, Reset Button | Frequency |
| 2.4 GHz, 5 GHz | Wireless |
Transmission Distance: Indoor up to 100m, outdoor up to 300m (it is limited in an environment)
| Interface | LAN 4x 10/100/ Auto MDI/MDIX RJ45 port WAN 1x 10/100/ Auto MDI/MDIX RJ45 port |
|---|
| Network Standard | 2.4GHz: IEEE802.11n, IEEE802.11g, IEEE 802.11b 5.0GHz: 802.11ac, IEEE 802.11n, IEEE 802.11a, IEEE802.3. IEEE802.3u, IEEE802.3ab |
|---|---|
| Encryption | 64/128-bits WEP, WPA/WPA2 |
| Others | Modulation: BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) Receive Sensitivity"PER: 11ac: -68dBm"10% PER; 11a: -68dBm"10% PER; 11n: -70dBm"10% PER 11g: -72dBm"10% PER; 11b: -85dBm"8% PER |
|---|
| Operating System Support | Microsoft Windows 8 SE/ NT/ 2000/ XP/ Vista/ 7/ 8/ 8.1/ 10, MAC OS, NetWare, UNIX or Linux |
|---|---|
| Physical Dimension | Dimension |
| 204.8 x 137. 5 x 38. 3mm | Color |
| White | Manufacturer warranty |
| Warranty | 1 year |
