| Key Features | Data Rate |
|---|---|
| 5GHz: 867Mbps 2.4GHz: 300Mbps | Antenna |
| 5*5dBi external antennas | Button |
| 1* Wi-Fi / Reset button | Frequency |
CE: 2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5250MHz(CH36-CH64) FCC: 2.4G: 2412-2462MHz(CH1-CH11) 5G: 5150-5250MHz(CH36-CH64) 5725-5825MHz(CH149-CH165)
| Interface | WAN, LAN |
|---|---|
| Network Standard | IEEE 802.11ac/a/n "5GHz IEEE 802.11b/g/n "2.4GHz |
| Encryption | WPA2-PSK Wireless Security: Enable /Disable |
| Ports | 1*10/100Mbps WAN port 3*10/100Mbps LAN ports |
| Others | 28nm high-performance chip MU-MIMO, Bandwidth Control, Tenda WiFi App, VPN Support Internet Connection Type PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Network Protocol IPv4&IPv6 Operating Mode Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） Parental Control Client Filter URL Filter Time Limit DHCP DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation Virtual Server Port Forwarding, DMZ Host, UPnP Firewall ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN DDNS DynDNS, no-ip, oray, 88ip VPN IPsec pass through PPTP pass through L2TP pass through Special Features Guest Network IPTV Signal Adjustment Basic Functions PPPoE Username/password Clone Smart WiFi Schedule Smart Power Saving Smart LED on/off Tenda App Dual-band in One IPv6 Features Supported Broadband management MAC address clone Backup & Restore configurations Firmware upgrade from local |
|---|---|
| Power Source | Power Mode |
| Input: 100-240V—50/60Hz 0.4A Output: DC 9V1A | Physical Dimension |
| Dimension | 220mm*141.5mm*49mm(L*W*H) |
| Color | Black |
| Manufacturer warranty | Warranty |
01 Year Warranty
